SKU: 5132051

CLASSIC FLAT 132-III

Sale price€220,65

Tax included. Shipping calculated at checkout

Select please: Chrom Gebürstet
Flügelfarbe: Buche und Nussbaum
Lieferzeit
Im Durchschnitt dauert die Lieferung 2-4 Tage

5 % Rabatt ab 500 € Einkaufswert
Für Privat- und Geschäftskunden
Ab 50 € Versandkostenfrei
Projektanfrage? Sichern Sie sich exklusive Konditionen bei größeren Bestellungen!

data sheet

The alternative to the classic ROYAL model is called FLAT and is an adaptation to ceilings with a height of 2.4 meters and less. Its wings are only about 16 cm from the ceiling and therefore protrude less deeply into the room. It offers the same quality and comfort as the ROYAL. The FLAT model can also be combined according to your personal taste with the available surface-mounted lights and replacement blades to create your individual highlight.

Design - ceiling fan in an elegant, classic design. Housing galvanically treated and clear coated (metal finish) or painted in two layers (lacquer finish). 5 multi-layered wooden wings with rattan inlay, painted or coated with decor and sealed.
Safety - Protection class I, max. ambient temperature 45 °C, radio interference suppressed.
Quality - Ball-bearing, life-lubricated and self-cooling motor, dynamically balanced, with thermal overload protection for whisper-quiet operation.
Variety - Available in 4 housing colors: antique or polished brass, shiny chrome or white lacquer.
Control - Built-in 3-stage pull switch, forward/reverse operation via slide switch on the motor housing, speed controllable.
Easy to install - Quick and easy assembly.
Attention - Please note that due to the small distance between the wings and the ceiling, the air output is reduced compared to devices with ceiling rods.
Can be combined - replacement blades in many wood and paint colors can be combined - see ceiling fans accessories.



Size Ø (cm): 132


Wing number: 5
Wing extras: Exchange wings possible, reversible wings, additional wings possible
Number of steps: 3 levels with pull switch
Steering: Remote control possible, wall switch possible, forward/reverse operation, with pull switch
Motor power min. (W): 9
Motor power max. (W): 65
Speed max. (rpm): 180
Voltage (V/Hz): 230/~50/60
Particularities: extra flat, only on straight ceilings
Style: classic

Can be combined - replacement blades in many wood and paint colors can be combined - see ceiling fans accessories.
Powerful - The powerful yet very quiet motor ensures good air performance with optimized energy consumption.
Environmentally friendly - After the life cycle, all parts can be dismantled for recycling.
Accessories - Wall transformers and controllers, remote controls, control relays, replacement wings, suspension systems for suspended ceilings, SLOW MOTION and longer pull chains are available as accessories.
Incredible - Thanks to the unique CasaFan combination system, where you can be sure that the controls as well as replacement sashes or the new natural sashes fit together exactly, you have more than 1400 combination options with the FLAT model alone. Put together your individual ceiling fan!

Eigenschaften
Watt
68
Watt
68
Watt
68
Watt
68
Watt
68

Angaben gemäß EU-Produktsicherheitsrichtlinie:

CasaFan GmbH Senefelderstr. 8 63594 Hasselroth Land: DE E-Mail: info@ventilator.de www.ventilator.de
